Tech Specs
| LED | 30x OSRAM P8 + 6x CREE XP20 | |
| RAW LUMENS | 19,020 Lm (each) | |
| TESTED LUMENS | 12,385 Lm (each) | 24,770 Lm (Pair) | |
| AMP DRAW | 4.5A @ 24v (each) | |
| POWER DRAW | 108W (each) | |
| CANDELA | 601,464 (Single) / 1,202,928(Pair) | |
| BEAM PATTERN | Combo (32 Spot + 4 Flood) | |
| INGRESS PROTECTION | IP68 | Submersible up to 3m | |
| COLOUR TEMP (CCT) | 5000K | |
| VOLTAGE COMPATIBILITY | 10v & 30v | |
| LUMEN MAINTENANCE | 50,000 LM-80 | |
| WEIGHT | 3.35kg (each) | |
| OPERATING TEMP | -40°C – 60°C | |
| PHOTOMETRIC DATA | ||
| 770 m | 1 Lx (Single) | |
| 1,192 m | 1 Lx (Pair) |
What’s Included
- 2 x STEDI™ 8.5″ Type-X™ Sport Plus LED Driving Lights Black
- 2 x Protective STEDI™ Blackout Covers
- 2 x Orange Coloured Fascias
- 2 x Grey Coloured Fascias
- 2 x Orange Coloured Shoulder Trim
- 2 x Grey Coloured Shoulder Trim
- 1 x Fascia Key Tool
- 1 x STEDI™ Smart High Beam Wiring Harness
- 2 x Stainless Steel Mounting Brackets
- 2 x Mounting Hardware (Set)
- 2 x Bracket Shock Dampeners
- 1 x Wiring & Fitting Instructions
